This 3.3mm cobalt stub drill manufactured to DIN 1897 is a short-length twist drill designed for accurate, rigid drilling of small holes in metal where minimal flex and fast chip evacuation are required. Its primary use is in precision metalworking, maintenance and toolroom operations where a stub-length flute gives better concentricity and reduced breakage compared with jobber-length drills.

Material and construction are high-speed steel with cobalt (HSSE, commonly M35 grade with approximately 5% cobalt) to provide improved red-hardness and wear resistance over conventional HSS. The drill is supplied with a straight (cylindrical) shank designed for standard three-jaw chucks and toolholders, a two-flute twist geometry and a standard 118° point angle for general-purpose metal drilling. Flutes are ground to a bright finish to aid chip formation and reduce built-up edge. The product is produced to DIN 1897 dimensional and tolerance requirements and is compatible with equivalent ISO and BS toolmaking conventions for stub drills.

Typical applications include drilling mild and alloy steels, stainless steels, castings and other difficult-to-machine ferrous materials found in automotive, aerospace, oil & gas maintenance, mould and die work, and general engineering workshops. The cobalt content makes this drill better suited to intermittent cutting and higher cutting temperatures than plain HSS, extending tool life when working with tougher materials.

Key benefits include enhanced hot hardness and wear resistance from the cobalt alloy, increased strength compared with standard HSS allowing higher cutting speeds, and the stub geometry which improves rigidity and hole accuracy while reducing the chance of breakage in small diameters. The bright ground finish offers some resistance to corrosion in storage and handling; for environments requiring long-term corrosion protection, coated or stainless options should be considered. The drill is compatible with conventional cutting fluids and standard drill chucks and holders.

Duchy Fasteners stocks cobalt stub drills across a wide range of metric diameters and supplies them individually or in multi-packs; contact us for available sizes, pack quantities and bulk pricing.
